Description
| Model | RTYD3.5ACP |
| Product Name | EV Car Charging Pile |
| Output Power Rating | 3.5-22Kw |
| Input Voltage range | 220V±15% |
| Input Frequency | 45-60HZ |
| Nominal current | 16-32A |
| Charging joint | 1 |
| Protection Grade | IP54 |
| Charger Plug | connection C |
| Temp. | -20℃~50 ℃ |
| Store temp. | -40℃~70 ℃ |
| Leak protection | 30mA |
| MTBF | 50000hours |
| Dielectric strength | ≥2000V |
| Screen | 4.3inch/no screen |
| Case Material | Plastic |
| Cable Length | 5 meters |
| Start Mode | Swip card/Scan |
| Installation | Wall-mounted |
| Standard | CE |
| Protection | Over Current, Under Voltage, Over Voltage, Short Circuit, Residual Current, Surge Protection, Over Temperature, Ground Protection |
| Mainbody Size | 270mmx130mmmx400mm |
